ASUS TUF GAMING X870-PRO WIFI7 W NEO Ryzen AM5 ATX Gaming Motherboard
ASUS TUF GAMING X870-PRO WIFI7 W NEO Ryzen AM5 ATX Gaming Motherboard
ASUS TUF GAMING X870-PRO WIFI7 W NEO Ryzen AM5 ATX Gaming Motherboard
ASUS TUF GAMING X870-PRO WIFI7 W NEO Ryzen AM5 ATX Gaming Motherboard

ASUS TUF GAMING X870-PRO WIFI7 W NEO Ryzen AM5 ATX Gaming Motherboard

Key Features of TUF GAMING X870-PRO WIFI7 W NEO:
Chipset: AMD X870 Chipset for AMD Ryzen 9000 & 8000 & 7000 Series
Socket: AMD Socket AM5
Memory: 4 x DIMM slots, max. 256GB, DDR5
Storage: Total supports 4 x M.2 slots and 2 x SATA 6Gb/s ports
Features: Advanced AI PC-ready, WiFi 7, AI Networking II, M.2 Heatsinks, Aura Sync, Addressable RGB Gen 2 Headers, DIY-Friendly Design
ASUS TUF GAMING X870-PRO WIFI7 W NEO Ryzen AM5 ATX Gaming Motherboard
৳0.00
Add to Cart
Specification Description Reviews
Specification:
Key Features
attr - Key Feature 1 > Chipset: AMD X870 Chipset for AMD Ryzen 9000 & 8000 & 7000 Series
attr -Key Feature 2 > Socket: AMD Socket AM5
attr -Key Feature 3 > Memory: 4 x DIMM slots, max. 256GB, DDR5
attr -Key Feature 4 > Storage: Total supports 4 x M.2 slots and 2 x SATA 6Gb/s ports
attr -Key Feature 5 > Features: Advanced AI PC-ready, WiFi 7, AI Networking II, M.2 Heatsinks, Aura Sync, Addressable RGB Gen 2 Headers, DIY-Friendly Design
Motherboard
Model TUF GAMING X870-PRO WIFI7 W NEO
CPU AMD Socket AM5 for AMD Ryzen 9000 & 8000 & 7000 Series Desktop Processors*
* Refer to https://www.asus.com/support/download-center/ for the CPU support list.
Chipset AMD X870 Chipset
Memory 4 x DIMM slots, max. 256GB, DDR5
Supports up to
8600+MT/s(OC)*/8200+MT/s(OC)** with Ryzen 9000 Series Processors,
9600+MT/s(OC)*/9000+MT/s(OC)** with Ryzen 8000 Series Processors,
8000+MT/s(OC)*/8000+MT/s(OC)** with Ryzen 7000 Series Processors,
ECC and Non-ECC Un-buffered DIMM***
Dual-channel memory architecture
Supports AMD Extended Profiles for Overclocking (EXPO)
Supports DIMM Fit and DIMM Fit Pro
NitroPath DRAM Technology
ASUS Enhanced Memory Profile (AEMP)

* Max Manual Overclocking: Achievable with advanced BIOS configuration and potentially specialized hardware. Passed AIDA64 memory benchmark at this frequency, verifying read/write bandwidth.
Results may vary according to system components. ** XMP/EXPO/AEMP Profiles: Rated memory module speeds require setting the BIOS performance profile.
Results may vary according to system components and can be impacted when four DIMM slots are used. For XMP/EXPO/AEMP profile settings, please visit https://rog.asus.com/support/faq/1042256/.
*** Non-ECC, un-buffered DDR5 memory supports On-Die ECC function.
*** Supported memory types, data rate (speed), and number of DRAM modules vary depending on the CPU and memory configuration.
For more information, please refer tothe CPU/Memory Support list under the Support tab of the product information site or visit https://www.asus.com/support/download-center/.
Adjustments will be made based on the specifications of mass-produced memory products available on the market.
Graphics 1 x HDMI port**
2 x USB4 (40Gbps) ports support USB Type-C display outputs***

* Available only on processors featuring integrated graphics. Graphics specifications may vary between CPU types. Please refer to AMD CPU specifications.
** Supports 4K@60Hz as specified in HDMI 2.1.
*** Supports max. 4K@60Hz as specified in DisplayPort 1.4a.
Expansion Slots AMD Ryzen 9000 & 7000 Series Desktop Processors*
1 x PCIe 5.0 x16 slot (supports x16 mode)

AMD Ryzen 8000 Series Desktop Processors
1 x PCIe 4.0 x16 slot (supports x8/x4 mode)**

AMD X870 Chipset
1 x PCIe 4.0 x16 slot (supports x4 mode)***

* Please check the PCIe bifurcation table on the support site (https://www.asus.com/support/FAQ/1037507/).
** Specifications vary by CPU types.
*** PCIEX16(G4) slot shares bandwidth with the The M.2_4 slot. When either the PCIEX16(G4) or M.2_4 slot is occupied, that slot runs at PCIe 4.0 x4 mode.
When both slots are occupied, each runs at PCIe 4.0 x2 mode. You can enter the BIOS to adjust the default settings as required.
- To ensure compatibility of the device installed, please refer to https://www.asus.com/support/download-center/ for the list of supported peripherals.
LAN WOL by PME, PXE
Storage Total supports 4 x M.2 slots and 2 x SATA 6Gb/s ports
AMD Ryzen 9000 & 7000 Series Desktop Processors
M.2_1 slot (Key M), type 2280 (supports PCIe 5.0 x4 mode)
M.2_2 slot (Key M), type 2280 (supports PCIe 5.0 x4 mode)*

AMD Ryzen 8000 Series Desktop Processors
M.2_1 slot (Key M), type 2280 (supports PCIe 4.0 x4 mode)
M.2_2 slot (Key M), type 2280 (supports PCIe 4.0 x4 mode)**

AMD X870 Chipset
M.2_3 slot (Key M), type 2280 (supports PCIe 4.0 x4 mode)
M.2_4 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 4.0 x4)***
2 x SATA 6Gb/s ports

* The 2 x USB4 (40Gbps) ports share bandwidth with the M.2_2 slot. The USB4 Controller runs at PCIe 4.0 x2 mode when a device is installed in the M.2_2 slot.
The M.2_2 slot runs at PCIe x2 mode by default. You can switch M.2_2 to M.2_2 X4 mode in the BIOS, but this will disable the USB4 (40Gbps) ports.
** Specifications vary by CPU types.
*** The M.2_4 slot shares bandwidth with the PCIEX16(G4) slot. When either the PCIEX16(G4) or M.2_4 slot is occupied, that slot runs at PCIe 4.0 x4 mode.
When both slots are occupied, each runs at PCIe 4.0 x2 mode. You can enter the BIOS to adjust the default settings as required.
Ethernet 1 x Realtek 5Gb Ethernet
TUF LANGuard
Wireless & Bluetooth Wi-Fi 7 (Realtek RTL8922AE)
2x2 Wi-Fi 7* (802.11be)
Supports 2.4/5/6GHz frequency band**
Supports Wi-Fi 7 160MHz bandwidth
Bluetooth v5.4 (support LE Audio)***

* Wi-Fi features may vary depending on the operating system.
For Windows 11, Wi-Fi 7 will require a version 24H2 or later for full functionality. Windows 11 21H2/22H2/23H2 only support Wi-Fi 6E.
For Windows 10, only Wi-Fi 6 is supported.
** Wi-Fi 6GHz frequency band and bandwidth regulations may vary between countries.
*** The Bluetooth version may vary; please refer to the Wi-Fi module manufacturer's website for the latest specifications.
USB Rear USB (Total 10 ports)
2 x USB4 (40Gbps) ports (2 x USB Type-C)*
3 x USB 10Gbps ports (3 x Type-A)
4 x USB 5Gbps ports (4 x Type-A)
1 x USB 2.0 port (1 x Type-A)

Front USB (Total 9 ports)
1 x USB 20Gbps connector (supports USB Type-C with up to 30W PD/PPS Fast-charge )**
1 x USB 5Gbps header supports 2 additional USB 5Gbps ports
3 x USB 2.0 headers support 6 additional USB 2.0 ports

* USB Type-C power delivery output: max. 5V/3A.
* The 2 x USB4 (40Gbps) ports share bandwidth with the M.2_2 slot. The USB4 Controller runs at PCIe 4.0 x2 mode when a device is installed in the M.2_2 slot. The M.2_2 slot runs at PCIe x2 mode by default.
You can switch M.2_2 to M.2_2 X4 mode in the BIOS, but this will disable the USB4 (40Gbps) ports.
** USB Type-C power delivery output: 5V/9V max. 3A, 12 V max. 2.5A, 15 V max. 2.0.
Audio Realtek ALC1220P 7.1 Surround Sound High Definition Audio CODEC*
- Impedance sense for front and rear headphone outputs
- Internal audio Amplifier to enhance the highest quality sound for headphones and speakers
- Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking
- High quality 120 dB SNR stereo playback output and 113 dB SNR recording input (Line-in)
- Supports up to 32-bit/192 kHz playback**

Audio Features
- Audio Shielding
- Premium audio capacitors
- Dedicated audio PCB layers
- Audio cover
- Unique de-pop circuit

* A chassis with an HD audio module in the front panel is required to support 7.1 Surround Sound audio output.
**Due to limitations in HDA bandwidth, 32-bit/192 kHz is not supported for 7.1 Surround Sound audio. **
Back Panel I/O Ports 2 x USB4 (40Gbps) ports (2 x USB Type-C)
3 x USB 10Gbps ports (3 x Type-A)
4 x USB 5Gbps ports (4 x Type-A)
1 x USB 2.0 port (1 x Type-A)
1 x HDMI port
1 x Wi-Fi module
1 x Realtek 5Gb Ethernet port
3 x Audio jacks
1 x BIOS FlashBack button
1 x Clear CMOS button
Internal I/O Connectors Fan and Cooling Related
1 x 4-pin CPU Fan header
1 x 4-pin CPU OPT Fan header
1 x 4-pin AIO Pump header
4 x 4-pin Chassis Fan headers
1 x W_PUMP+ header

Power Related
1 x 24-pin Main Power connector
2 x 8-pin +12V CPU Power connectors

Storage Related
4 x M.2 slots (Key M)
2 x SATA 6Gb/s ports

USB
1 x USB 20Gbps connector (supports USB Type-C with up to 30W PD/PPS Fast-charge )
1 x USB 5Gbps header supports 2 additional USB 5Gbps ports
3 x USB 2.0 headers support 6 additional USB 2.0 ports

Miscellaneous
3 x Addressable RGB Gen 2 headers
1 x Chassis Intrusion header
1 x COM Port header
1 x Front Panel Audio header (F_AUDIO)
1 x S/PDIF Out header
1 x 10-1 pin Front Panel System header
1 x Thermal Sensor header
Special Features Asynchronous Clock
ASUS TUF PROTECTION
- DIGI+ VRM (- Digital power design with SPS)
- ESD Guards
- TUF LANGuard
- Overvoltage protection
- SafeSlot
- Stainless-steel back I/O

ASUS Q-Design
- M.2 Q-Latch
- M.2 Q-Release
- PCIe Slot Q-Release
- Q-Antenna
- Q-Dashboard
- Q-DIMM
- Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green])
- Q-Slot

ASUS Thermal Solution
- M.2 heatsink
- VRM heatsink design
ASUS EZ DIY
- BIOS FlashBack button
- BIOS FlashBack LED
- Clear CMOS button
- Dual DIMM clips
- ProCool
- Pre-mounted I/O shield
- SafeDIMM

Aura Sync
- Addressable RGB Gen 2 headers

Front Panel USB 20Gbps with PD Fast Charge Support
- Support: up to 30W fast charging and USB Wattage Watcher
- Output: 5V/9V max. 3A, 12 V max. 2.5A, 15 V max. 2.0A
- Compatible with PD3.0
Software Features ASUS Exclusive Software
Armoury Crate
- Aura Creator
- Aura Sync
- Fan Xpert 4 (with AI Cooling II)
- WiFi Q-Antenna
- MLO Wizard

ASUS DriverHub
- ASUS MB Manager
- ASUS AI Advisor
- TUF GAMING CPU-Z
- ASUS GlideX
- USB Wattage Watcher
- TurboV Core
- Norton 360 for Gamers (60 Days Free Trial)
- WinRAR (40 Days Free Trial)
DTS Audio Processing
Adobe Creative Cloud (Free Trial)**

UEFI BIOS
Integrated WiFi Driver Support
AI Overclocking Guide
AI Cache Boost

ASUS EZ DIY
- ASUS CrashFree BIOS 3
- ASUS EZ Flash
- ASUS UEFI BIOS EZ Mode
- ASUS MyHotkey

* For more software features, please visit the Asus support site or refer to www.asus.com/support for additional information.
** For detailed information on the supported models and restricted regions for this redemption offer, please refer to https://www.asus.com/content/asus-offers-adobe-creative-cloud/.
BIOS 64MB (512Mb) Flash ROM, UEFI AMI BIOS
Manageability WOL by PME, PXE
Accessories Cables
2 x SATA 6Gb/s cables

Miscellaneous
1 x ASUS WiFi Q-Antenna
1 x TUF Gaming sticker
2 x M.2 rubber packages
1 x Screw package for M.2 SSD

Documentation
1 x Quick start guide
Operating System Windows 11
Form Factor ATX Form Factor
12 inch x 9.6 inch ( 30.5 cm x 24.4 cm )
RAID Support AMD RAIDXpert2 Technology
Ryzen 9000 & 8000 & 7000 Series Processors: RAID 0/1/5/10
Warranty 3 Years Replacement Warranty *(Terms and Conditions Applied)
Description:

ASUS TUF GAMING X870-PRO WIFI7 W NEO Ryzen AM5 ATX Gaming Motherboard Price in Bangladesh

ASUS TUF GAMING X870-PRO WIFI7 W NEO Ryzen AM5 ATX Gaming Motherboard

The ASUS TUF GAMING X870-PRO WIFI7 W NEO Ryzen AM5 ATX Gaming Motherboard is built for AMD Ryzen 9000 and 7000 series processors for stable performance, strong power delivery, and next-generation connectivity for gaming and AI-focused workloads. Built on an AM5 socket with an eight-layer server-grade PCB, it ensures clean signal transfer, long-term durability, and reliable operation under heavy loads.

The motherboard also includes a 16+2+1 phase power stage design rated for 80A, with enlarged VRM heatsinks and ProCool 8+8 pin connectors to provide stable power delivery with effective cooling. DDR5 memory support goes up to 9600+, at a minimum of MT/s OC, complemented by NitroPath DRAM Technology, AEMP, EXPO support, and BIOS tuning options. The motherboard is ready for expansion with one PCIe 5.0 x16 SafeSlot for graphics cards, two PCIe 5.0 M.2 slots, and more PCIe 4.0 M.2 slots with dedicated heatsinks. It also features a dual USB4 40Gbps Type-C, a front USB 20Gbps Type-C with up to 30W fast charging, multiple USB 10Gbps and 5Gbps, WiFi 7, and 5Gb Ethernet for low-latency gaming and fast data transfer.

Features like AI Cache Boost, AI Overclocking, AI Cooling II, AI Advisor, and AI Networking II assist in managing performance, cooling, and networking with less configuration. The tools are quite helpful and oriented toward do-it-yourselfers and come with features such as PCIe Slot Q-Release, M.2 Q-Latch, BIOS FlashBack, Clear CMOS, and Q-LED. Audio is fueled by Realtek ALC1220P audio codec with DTS Audio Processing and Realtek Audio with LE Audio support, and Aura Sync RGB and Gen 2 headers for all-system lighting control capabilities. This motherboard is designed specifically for gaming, fast storage solutions, and ultimate performance capabilities of the future.

Buy ASUS TUF GAMING X870-PRO WIFI7 W NEO Ryzen AM5 ATX Gaming Motherboard in Bangladesh

You can buy your desired ASUS TUF GAMING X870-PRO WIFI7 W NEO Ryzen AM5 ATX Gaming Motherboard at Global Brand PLC. We are the authorized distributor of Asus in Bangladesh. You buy online and enjoy free home delivery. You can also visit any of our branches near you.
