UGREEN US316 (20478) USB-C to USB-C PD Fast Charging Cable - 0.5M
UGREEN US316 (20478) USB-C to USB-C PD Fast Charging Cable - 0.5M
UGREEN US316 (20478) USB-C to USB-C PD Fast Charging Cable - 0.5M

UGREEN US316 (20478) USB-C to USB-C PD Fast Charging Cable - 0.5M

Key Features of US316 (20478):
100W Fast Charging
Reliable Data Transfer – Supports 480 Mbps
Built-in HUSB332A E-marker Charging Chip
Strong Build Quality
Warranty: 01-Year Brand Warranty
UGREEN US316 (20478) USB-C to USB-C PD Fast Charging Cable - 0.5M
৳400.00
Specification:
Key Features
attr - Key Feature 1 > 100W Fast Charging
attr -Key Feature 2 > Reliable Data Transfer – Supports 480 Mbps
attr -Key Feature 3 > Built-in HUSB332A E-marker Charging Chip
attr -Key Feature 4 > Strong Build Quality
attr -Key Feature 5 > Warranty: 01-Year Brand Warranty
Additional Info
Additional Info Brand: Ugreen
Model: US316 (20478)
Product Name: UGREEN USB-C PD Fast Charging Cable
Length: 0.5M

Core Structure (0.25–1m):
Signal Wires: 30 AWG (19/0.06TS + 250D) * 1P (white/green)
CC Wires: 30 AWG (19/0.06TS + 250D) * 2C (blue/yellow)
Power Wires: 24 AWG (41/0.08TS + 250D), 16/0.08TS + 250D * 3C
Outer Braiding: F (500D nylon strands), ALC silver/TC woven mesh

Diameter:
Before Weaving: 3.9 ± 0.1 mm
After Weaving: 4.4 ± 0.15 mm

Material:
Core: Tin-coated copper
Coating: TPE
Shielding: Aluminum foil + braided

Connectors:
USB-C 2.0/M
Black rubber core
Gold-plated terminals (15U")
Stainless steel nickel-plated shell
HUSB332A chip + 10nF capacitor

Wire Core Counts:
0.25–1m: 6 cores + 3 ground
1.5–2m: 6 cores + 5 ground
3m: 6 cores + 6 ground

Current Capacity: Up to 5A
Data Transfer: USB 2.0, up to 480 Mbps
Charging Power: Up to 100W (20V/5A Max)
Charging Protocols: PD, SCP, PPS

Durability:
Insertion life: 10,000 times
Bending Test: 3,000 swings at ±90°, 300g weight
Flame Retardant Grade: GB/T 5169.23-2008
Operating Temp: 0°C to 45°C
Storage Temp: -15°C to 70°C

Certifications: RoHS 2.0, REACH, SVHC, POPs, California 65, TSCA, China RoHS
Description:

UGREEN US316 (20478) USB-C to USB-C PD Fast Charging Cable - 0.5M Price in Bangladesh

UGREEN US316 (20478) USB-C to USB-C PD Fast Charging Cable - 0.5M

UGREEN US316 (20478) USB-C to USB-C PD Fast Charging Cable - 0.5M is intended for quick and secure charging of a wide range of USB-C devices. It supports a power output of up to 100W and follows PD, SCP, and PPS protocols to meet the requirements of phones, tablets, laptops, and other devices for quick and stable charging. The cable makes use of tin-coated copper with TPE outer casing and black and silver woven mesh for strength. The internal structure of the cable is well planned: 0.25 to 1 meter has 6 cores and 3 floors, longer lengths, such as 1.5–2 meters have 5 floors, and 3 meters has 6 floors. The cable is able to transfer 480 Mbps with the USB 2.0 standard, perfect both for charging and syncing.

The black rubber core, the gold-plated 15U" terminals, and the nickel-plated stainless steel shell are all features of the male-type USB-C 2.0 connectors. The plugs contain a 10nF capacitor and a HUSB332A chip for intelligent current control. The cable diameter is 3.9±0.1mm before weaving and 4.4±0.15mm after weaving, with stable build quality that withstands 10,000 plug-in tests and 3,000 swing tests (±90°, 300g, 30 times/min).

The cable supports a wide voltage range—5V/3A, 9V/2A, 9V/3A, 15V/2A, 15V/3A, 20V/3A, and 20V/5A—and is therefore perfect for high-power devices. The cable is also in compliance with international environmental and safety standards, including RoHS 2.0, REACH, SVHC, POPs, California 65, TSCA, and China RoHS. It is flame retardant according to GB/T 5169.23-2008 standards. The working temperature is 0~45°C while the storage range is -15~70°C. This makes it a great and long-lasting option for daily charging purposes.

Buy UGREEN US316 (20478) USB-C to USB-C PD Fast Charging Cable - 0.5M in Bangladesh

You can buy your desired UGREEN US316 (20478) USB-C to USB-C PD Fast Charging Cable - 0.5M at Global Brand PLC. We are the authorized distributor of UGREEN in Bangladesh. You buy online and enjoy free home delivery. You can also visit any of our branches near you.
