ASUS ROG STRIX B850-F GAMING WIFI7 NEO AMD AM5 ATX Gaming Motherboard
ASUS ROG STRIX B850-F GAMING WIFI7 NEO AMD AM5 ATX Gaming Motherboard
ASUS ROG STRIX B850-F GAMING WIFI7 NEO AMD AM5 ATX Gaming Motherboard
ASUS ROG STRIX B850-F GAMING WIFI7 NEO AMD AM5 ATX Gaming Motherboard
ASUS ROG STRIX B850-F GAMING WIFI7 NEO AMD AM5 ATX Gaming Motherboard

ASUS ROG STRIX B850-F GAMING WIFI7 NEO AMD AM5 ATX Gaming Motherboard

Key Features of ROG STRIX B850-F GAMING WIFI7 NEO:
Chipset: AMD B850 Chipset
Socket: AMD Socket AM5
Memory: 4 x DIMM slots, max. 256GB, DDR5
Storage: Total supports 4 x M.2 slots and 2 x SATA 6Gb/s ports
Features: WiFi 7, ASUS AI Intelligence, EZ PC DIY, Aura Sync
ASUS ROG STRIX B850-F GAMING WIFI7 NEO AMD AM5 ATX Gaming Motherboard
৳0.00
Add to Cart
Specification Description Reviews
Specification:
Key Features
attr - Key Feature 1 > Chipset: AMD B850 Chipset
attr -Key Feature 2 > Socket: AMD Socket AM5
attr -Key Feature 3 > Memory: 4 x DIMM slots, max. 256GB, DDR5
attr -Key Feature 4 > Storage: Total supports 4 x M.2 slots and 2 x SATA 6Gb/s ports
attr -Key Feature 5 > Features: WiFi 7, ASUS AI Intelligence, EZ PC DIY, Aura Sync
Motherboard
Model ROG STRIX B850-F GAMING WIFI7 NEO
CPU AMD Socket AM5 for AMD Ryzen™ 9000 & 8000 & 7000 Series Desktop Processors*
* Refer to https://www.asus.com/support/download-center/ for the CPU support list.
Chipset AMD B850 Chipset
Memory 4 x DIMM slots, max. 256GB, DDR5
Supports up to 9000+MT/s (OC)**, ECC and Non-ECC
Supports up to
8400+(OC)**/8200+(OC)*** MT/s with Ryzen 9000 Series Processors,
9000+(OC)**/8600+(OC)*** MT/s with Ryzen 8000 Series Processors,
8000+(OC)**/8000+(OC)*** MT/s Ryzen 7000 Series Processors,
ECC and Non-ECC, Un-buffered DIMM
*Dual channel memory architecture supports AMD Extended Profiles for Overclocking (EXPO), ASUS Enhanced Memory
Profile (AEMP)* Non-ECC, un-buffered DDR5 memory supports On-Die ECC function.
** Max Manual Overclocking: Achievable with advanced BIOS configuration and potentially specialized hardware.
Results may vary according to system components.
*** XMP/EXPO/AEMP Profiles: Rated memory module speeds require a BIOS performance profile setting. Results may
vary according to system components and can be impacted when four DIMM slots are used.
**** Supported memory types, data rate (speed), and number of DRAM modules vary depending on the CPU and
memory configuration. For more information, please refer to the CPU/Memory Support list under the Support tab of the
product information site or visit https://www.asus.com/support/download-center/. Adjustments will be made based on the
specifications of mass-produced memory products available on the market.
Graphics 1 x HDMI port**
* Available only on processors featuring integrated graphics. Graphics specifications may vary between CPU types.
Please refer to AMD CPU specifications.
** Supports 4K@60Hz as specified in HDMI 2.1.
Expansion Slots AMD Ryzen 9000 & 7000 Series Desktop Processors*
1 x PCIe 5.0 x16 slot (supports x16 mode)
AMD Ryzen 8700 & 8600 & 8400 Series Desktop Processors*
1 x PCIe 4.0 x16 slots (supports x8 mode)
AMD Ryzen 8500 & 8300 Series Desktop Processors*
1 x PCIe 4.0 x16 slots (supports x4 mode)
AMD B850 Chipset
1 x PCIe 4.0 x16 slot (supports x4 mode)**
* Specifications vary by CPU types.
** PCIEX16(G4) slot (supports x4 mode) from AMD B850 Chipset shares bandwidth with M.2_3
To ensure compatibility of the device installed, please refer to https://www.asus.com/support/download-center/ for the list of supported peripherals.
Storage Total supports 4 x M.2 slots and 2 x SATA 6Gb/s ports
AMD Ryzen 9000 & 7000 Series Desktop Processors
M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode)
M.2_2 slot (Key M), type 2280 (supports PCIe 5.0 x4 mode)
AMD Ryzen 8700 & 8600 & 8400 Series Desktop Processors
M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)
M.2_2 slot (Key M), type 2280 (supports PCIe 4.0 x4 mode)
AMD Ryzen 8500 & 8300 Series Desktop Processors
M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)
M.2_2 slot (Key M), type 2280 (supports PCIe 4.0 x2 mode)
AMD B850 Chipset
M.2_3 slot (Key M), type 2280 (supports PCIe 4.0 x4)**
M.2_4 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4)
2 x SATA 6Gb/s ports
* M.2_3 slot shares bandwidth with PCIEX16(G4). When PCIEX16(G4) slot is operating, M.2_3 will be disabled.
Ethernet 1 x Realtek 5Gb Ethernet
ASUS LANGuard
Wireless & Bluetooth Wi-Fi 7 (MediaTek MT7925)
2x2 Wi-Fi 7* (802.11be)
Supports 2.4/5/6GHz frequency band**
Supports Wi-Fi 7 160MHz bandwidth
Bluetooth v5.4 (supports LE Audio)***
*Wi-Fi features may vary depending on the operating system.
For Windows 11, Wi-Fi 7 will require 24H2 or later for full functions; Windows 11 21H2/22H2/23H2 only support Wi-Fi 6E.
For Windows 10, please note that no driver is available; please refer to the Wi-Fi chipset vendor's website for details.
** Wi-Fi 6GHz frequency band and bandwidth regulations may vary between countries.
*** The Bluetooth version may vary; please refer to the Wi-Fi module manufacturer's website for the latest specifications.
USB Rear USB (Total 12 ports)
4 x USB 10Gbps port(s) (2 x Type-A + 2 x USB Type-C)
6 x USB 5Gbps port(s) (5 x Type-A + 1 x USB Type-C)
2 x USB 2.0 port(s) (2 x Type-A)
Front USB (Total 7 ports)
1 x USB 20Gbps
2 x USB 5Gbps header(s) support(s) 4 additional USB 5Gbps ports
3 x USB 2.0 header(s) support(s) 6 additional USB 2.0 ports
* USB Type-C power delivery output: max. 5V/3A.
Audio ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4080*
Impedance sensing for front and rear headphone outputs
Supports: Jack detection, Multi-streaming, Front Panel MIC Jack-retasking
High-quality 120 dB SNR stereo playback output and 110 dB SNR recording input
Supports up to 32-Bit/384 kHz playback on front panel
Audio Features :
SupremeFX Shielding Technology
Savitech SV3H712 AMP
Rear optical S/PDIF out port
Premium audio capacitors
Audio cover
* A chassis with an HD audio module in the front panel is required to support 7.1 Surround Sound audio output.
** The LINE OUT port on the rear panel does not support spatial audio. If you wish to use spatial audio, make sure to connect
your audio output device to the audio jack on the front panel of your chassis or use a USB interface audio device.
Back Panel I/O Ports 4 x USB 10Gbps port(s) (2 x Type-A + 2 x USB Type-C)
6 x USB 5Gbps port(s) (5 x Type-A + 1 x USB Type-C)
2 x USB 2.0 port(s) (2 x Type-A)
1 x HDMI port
1 x Wi-Fi module
1 x Realtek 5Gb Ethernet port
2 x Audio jacks
1 x Optical S/PDIF out port
1 x BIOS FlashBack button
1 x Clear CMOS button
Internal I/O Connectors Fan and Cooling Related
1 x 4-pin CPU Fan header
1 x 4-pin CPU OPT Fan header
1 x 4-pin AIO Pump header
4 x 4-pin Chassis Fan headers
Power Related
1 x 24-pin Main Power connector
2 x 8-pin +12V CPU Power connector
Storage Related
4 x M.2 slots (Key M)
2 x SATA 6Gb/s ports
USB
1 x USB 20Gbps connector (support(s) USB Type-C )
2 x USB 5Gbps header(s) support(s) 4 additional USB 5Gbps ports
3 x USB 2.0 header(s) support(s) 6 additional USB 2.0 ports
Miscellaneous
3 x Addressable Gen 2 headers
1 x CPU Overvoltage jumper
1 x Front Panel Audio header (F_AUDIO)
1 x Power button
1 x 10-1 pin Front System Panel header
1 x Thermal Sensor header
1 x Thunderbolt (USB4) header
Special Features Extreme Engine Digi+:
5K Black metallic capacitors

ASUS Q-Design:
M.2 Q-Latch
M.2 Q-Release
M.2 Q-Slide
PCIe Slot Q-Release Slim (with PCIe SafeSlot)
Q-Antenna
Q-Dashboard
Q-DIMM
Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green])
Q-Slot
ASUS Thermal Solution: M.2 heatsink backplate M.2 heatsink ASUS EZ DIY: BIOS FlashBack button BIOS FlashBack LED Clear CMOS button ProCool Pre-mounted I/O shield SafeSlot SafeDIMM Aura Sync: Addressable Gen 2 headers
Software Features ROG Exclusive Software:
ROG CPU-Z
Dolby Atmos

ASUS Exclusive Software:
Armoury Crate
Aura Creator
Aura Sync
Fan Xpert 4 (with AI Cooling II)
GameFirst- WiFi Q-Antenna
MLO WizardASUS DriverHub
ASUS MB Manager
ASUS AI Advisor
AIDA64 Extreme (60 days free trial)
HWiNFO- ASUS GlideX
TurboV Core
Norton 360 for Gamers (60 Days Free Trial)
WinRAR (40 Days Free Trial)
Adobe Creative Cloud (Free Trial)**

UEFI BIOS
Integrated WiFi Driver
SupportAI Cache Boost
ASUS EZ DIY
ASUS CrashFree BIOS 3
ASUS EZ Flash 3
ASUS EZ Flash
ASUS UEFI BIOS EZ Mode
ASUS MyHotkeyFlexKey
*For more software features, please visit the ASUS support site or refer to
www.asus.com/support for additional information.
** For detailed information on the supported models and restricted regions for this redemption offer, please refer to
https://www.asus.com/content/asus-offers-adobe-creative-cloud/.
BIOS 64 MB (512Mb) Flash ROM, UEFI AMI BIOS
Manageability WOL by PME, PXE
Accessories Cables
2 x SATA 6Gb/s cables
Miscellaneous
1 x ASUS WiFi Q-Antenna
1 x Cable ties package
1 x M.2 Q-Latch package
1 x M.2 Q-Slide package
1 x ROG key chain
1 x ROG Strix stickers
3 x M.2 rubbers
1 x M.2 backplate rubber package(s)
Documentation
1 x Quick start guide
Operating System Windows 11
Form Factor ATX Form Factor
12 inch x 9.6 inch ( 30.5 cm x 24.4 cm )
RAID Support AMD RAIDXpert2 Technology
Ryzen 9000 & 8000 & 7000 Series Processors: RAID 0/1/5/10*
Warranty
Warranty Details 3 Years Replacement Warranty *(Terms and Conditions Applied)
Description:

ASUS ROG STRIX B850-F GAMING WIFI7 NEO AMD AM5 ATX Gaming Motherboard Price in Bangladesh

ASUS ROG STRIX B850-F GAMING WIFI7 NEO AMD AM5 ATX Gaming Motherboard

The ASUS ROG STRIX B850-F GAMING WIFI7 NEO AMD AM5 ATX Gaming Motherboard is made to cater to gamers, creatives, and next-generation PC applications such as AI. The AMD B850 chipset powers this motherboard and works with AMD Ryzen 9000, 8000, and 7000 Series desktop processors on the AM5 socket. The ASUS ROG STRIX B850-F GAMING WIFI7 NEO is equipped with a 16+2+2 power stage design, which comes with 80A-rated stages and dual ProCool power connectors. In addition, it has power management features for providing reliable power delivery for high-performance CPUs. ASUS ROG STRIX B850-F GAMING WIFI7 NEO works with DDR5 memory with a speed up to 9000+ MT/s (OC) with AMD EXPO™ and ASUS Enhanced Memory Profile (AEMP).

The motherboard allows you to use PCIe 5.0 with one PCIe 5.0 x16 SafeSlot and two PCIe 5.0 M.2 slots for graphics cards and next-generation storage devices. The board gives you four M.2 slots. It also gives you WiFi 7 connectivity, which includes 160MHz channels, 4096-QAM, 6GHz band support, and Realtek 5Gb Ethernet. This motherboard has ASUS AI features that include ASUS AI Cache Boost to increase the speed of performing local AI workloads, ASUS AI Cooling II that will automatically tune the fan speeds, ASUS AI Networking II, which optimizes the performance of the network, and ASUS AI Advisor for easy guidance of the motherboard.

The motherboard features an advanced cooling system with VRM Heatsink, M.2 Heatsinks with Backplate, CPU Fan Headers, AIO Pump, and many Chassis Fan Headers. SupremeFX Gaming Audio, Dolby Atmos, USB 20Gbps Connectivity, Aura Sync RGB Lighting, Q-LED, M.2 Q-Release, PCIe Slot Q-Release, BIOS FlashBack, and 64MB BIOS Chip, among others, are the outstanding features of this motherboard.

Buy ASUS ROG STRIX B850-F GAMING WIFI7 NEO AMD AM5 ATX Gaming Motherboard in Bangladesh

You can buy your desired ASUS ROG STRIX B850-F GAMING WIFI7 NEO AMD AM5 ATX Gaming Motherboard at Global Brand PLC. We are the authorised distributor of ASUS in Bangladesh. You buy online and enjoy free home delivery. You can also visit any of our branches near you.
