Tiandy TC-R3240 TC-R3232 4HA 2HDD 32ch AI NVR
Tiandy TC-R3240 TC-R3232 4HA 2HDD 32ch AI NVR
Tiandy TC-R3240 TC-R3232 4HA 2HDD 32ch AI NVR

Tiandy TC-R3240 TC-R3232 4HA 2HDD 32ch AI NVR

Key Features of TC-R3240 TC-R3232:
Up to 32-ch IP camera accesses
Incoming/Outgoing bandwidth: 160Mbps (AI on: 120Mbps)/80Mbps
16-ch synchronous playback
Up to 10 TB capacity for each HDD
Max. decoding capability: 16MP(30fps)×1 or 1080P(30fps)×10

CALL FOR DETAILS: +880 1973-439218
Tiandy TC-R3240 TC-R3232 4HA 2HDD 32ch AI NVR
৳0.00
Add to Cart
Specification Description Reviews
Specification:
Key Features
attr - Key Feature 1 > Up to 32-ch IP camera accesses
attr -Key Feature 2 > Incoming/Outgoing bandwidth: 160Mbps (AI on: 120Mbps)/80Mbps
attr -Key Feature 3 > 16-ch synchronous playback
attr -Key Feature 4 > Up to 10 TB capacity for each HDD
attr -Key Feature 5 > Max. decoding capability: 16MP(30fps)×1 or 1080P(30fps)×10
Call Info >

CALL FOR DETAILS: +880 1973-439218
Tiandy NVR
Video and Audio Access Channel: 32
Incoming Bandwidth: 160Mbps(AI on: 120Mbps)
Outgoing Bandwidth: 80Mbps
Resolution: 16MP/12MP/8MP/6MP/5MP/4MP/3MP/1080P/UXGA/720P/VGA/4CIF/DCIF/2CIF/CIF/QCIF

Preview Decoding Capability:
16MP(30fps)×1,8MP(30fps)×2, 6MP(30fps)×3, 5MP(30fps)×4, 4MP(30fps)×5, 3MP(30fps)×6,
1080P(30fps)×10, 720P(30fps)×20, 4CIF(30fps)×32
(AI on：16MP(30fps)×1,8MP(30fps)×2, 6MP(30fps)×2, 5MP(30fps)×3, 4MP(30fps)×4, 3MP(30fps)×5,
1080P(30fps)×8, 720P(30fps)×16, 4CIF(30fps)×32)

Playback Decoding Capability:
16MP(30fps)×1,8MP(30fps)×2, 6MP(30fps)×3, 5MP(30fps)×4, 4MP(30fps)×5, 3MP(30fps)×6,
1080P(30fps)×10, 720P(30fps)×16, 4CIF(30fps)×16
(AI on：16MP(30fps)×1,8MP(30fps)×2, 6MP(30fps)×2, 5MP(30fps)×3, 4MP(30fps)×4, 3MP(30fps)×5,
1080P(30fps)×8, 720P(30fps)×16)

Third-party Camera Access: ONVIF(Profile S/T); RTSP

HDMI Output:
HDMI: 1024×768(60Hz), (720P)1280×720(50Hz/60Hz), 1280×800(60Hz), 1280×1024(60Hz),
1440×900(60Hz), (1080P)1920×1080(50Hz/60Hz), (2K)2560×1440(30Hz), (4K)3840×2160(30Hz)

VGA Output:
VGA: 1024×768(60Hz), (720P)1280×720(50Hz/60Hz), 1280×800(60Hz), 1280×1024(60Hz),
1440×900(60Hz), (1080P)1920×1080(50Hz/60Hz)

Multi-screen Display:
Simultaneous Output:
VGA: 1/2A/2B/3/4/5/6/7/8/9/10/12/13/16/20A/20B/25/32/36
HDMI: 1/2A/2B/3/4/5/6/7/8/9/10/12/13/16/20A/20B/25/32/36

Audio Input: 1-ch, 3.5mm
Audio Output: 1-ch, RCA (Linear, 1 KΩ)
Two-Way Audio: 1-ch, 3.5mm, using the audio input
Compression Standard Video Compression: S+265; H.265; S+264; H.264
Audio Compression: G.711A; G.711U; AAC; ADPCM_D
Stream Type: Video; Video & Audio
Network Network Protocol:
802.1X; ARP; DDNS; DHCP; DNS; Easy DDNS; FTP; HTTP; HTTPS; ICMP; IGMP;
IPv4; IPv6; Multicast; NFS; NTP; PPPoE; QoS; RTCP; RTP; RTSP; SMB/CIFS; SMTP;
SNMP v1/v2/v3; SRTP; SSH; SSL; TLSv1.2; TCP; UDP; Unicast; UPnP

Mobile Client: EasyLive Plus (Android, iOS)
System Compatibility: ONVIF(Profile S/T/G); RTSP; CGI; SDK; P2P
Web: IE10+; Firefox52+; Edge89+; Safari11+; Chrome57+
Recording Playback Multi-channel Playback: 16
Record Mode: Manual Recording; Alarm Recording; Schedule Recording
Storage Method: Local HDD
Backup: USB storage device, Network

Playback Function:
Play/Pause/Stop/Reverse/Slow/Speed/Backwards 30s/Forwards 30s/Full Screen/
Backup (Video Editing)/Step/Digital Zoom/Instant Replay
Alarm General Alarm:Motion Detection; Mask Alarm; Alarm Input(IPC); Alarm Input(NVR)

Exceptions Alarm:
Video Loss; Network Disconnected; No Disk; Illegal Access; Disk group space alert;
Disk Full; Disk R/W Error; Recording Abnormal; Abnormal found in smart of disk; Abnormal temperature of the disk; Hot-spare Exception; Voltage Alarm(IPC); RTC Failure;
IP Address Conflict; MAC Address Conflict; Disk Overload
Intelligent Analytics AI by Camera:
Tripwire; Double Tripwire; Perimeter; Object Abandon; Object Missing; Running; Parking;
Heatmap; Loitering; Video Abnormal; Audio Abnormal; On Duty Detection; Crowd Detection;
Safety Helmet Detection; Electric Bicycle Detection; People Counting; Link to Tracking;
Smoke and Fire Detection; Environmental Temperature Measurement; Face Detection;
Human Body Temperature Measurement; Smart Alarm; Face Recognition; Human/Vehicle Classification

AI by NVR: Face Detection; Face Recognition; Tripwire; Double Tripwire; Perimeter; Smart Motion Detection

VCA Search:
Early-warning Search; Behavior Search; Safety Helmet Search; Thermographic Retrieval; Duty Search;
Electric Bicycle Retrieval; Face Search(Search by face attributes); Smart Motion Detection

VCA Report: Heatmap; People Counting; Face Statistics
Face Detection Face Attributes Detection: Gender; Age; Glasses; Face Mask
Face Attributes Search: Gender; Age; Glasses; Face Mask; Body Temp.
Face Recognition Face Recognition Performance: 1-ch(Max.5MP) video streams or 4-ch image streams
Face Picture Library: Up to 10 face libraries, up to 20000 base images
Face Picture Comparison: Yes
AI Performance (AI by NVR) Perimeter/Tripwire Performance: 4-ch
Smart Motion Dection Performance: 4-ch
Storage HDD Capacity: Up to 10 TB capacity for each HDD
Disk Group: 2 Disk Group
External Port USB: 2×USB2.0
HDMI: 1×HDMI(supports up to 4K resolution output)
VGA: 1×VGA
Network Interface: 1×RJ-45, 10/100/1000 Mbps self-adaptive Ethernet port
SATA: 2×SATA interface
Alarm I/O: 4-ch, TTL inputs, 3mA, 3.3VDC; 1-ch, relay output, 1A, 24VDC
General UI Language:
Simple Chinese; Traditional Chinese; English; Spanish; Korean; Italian; Turkish;
Russian; Thai; French; Polish; Dutch; Hebrew; Arabic; Vietnamese; German; Ukrainian;
Portuguese; Albanian; Indonesian; Greek

Power Supply: DC12V
Power Consumption: <10W(HDD not included, idling)
NetWeight: 1.6 kg
GrossWeight: 2.8kg
Boundary Dimensions: 341(L)280(W)47(H)mm
Package Dimensions: 415(L)140(W)375(H)mm
Operating Temperature: -10℃~+55℃ (+14℉~+131℉)
Operating Humidity: 10%~90%RH (non-condensing)
Storage Temperature: -20℃~+60℃ (-4℉~+140℉)

Package Kit:
Network Video Recorder*1; Screw Pack*2; Mouse*1; Power Adapter(DC12V 3A)*1;
European Standard Power Cord*1; Instructions*1; Parts List*1
Warranty 1-Year Brand Warranty
Description:

Tiandy TC-R3240 TC-R3232 4HA 2HDD 32ch AI NVR

Tiandy TC-R3240 TC-R3232 4HA 2HDD 32ch AI NVR is a smart network video recorder designed for AI-based IP surveillance systems. It supports up to 32 IP cameras with incoming bandwidth of 160Mbps, or 120Mbps when AI is enabled, and outgoing bandwidth of 80Mbps. It works with S+265, H.265, S+264, and H.264 video formats, where S+265 compression helps reduce storage use by up to 75% while keeping clear video quality. This AI NVR supports camera resolutions up to 16MP and provides stable decoding performance. It can decode one 16MP camera at 30fps or up to ten 1080P cameras at the same time, with AI mode adjusting decoding capacity as needed. It supports 16-channel synchronous playback and offers smooth preview and playback across different resolutions. HDMI and VGA outputs work at the same time, and HDMI supports display up to 4K resolution with flexible multi-screen layouts.

The device supports third-party IP cameras through ONVIF and RTSP and includes one gigabit Ethernet port for reliable network connection. It supports dual stream recording, cloud upgrade, and a wide range of network protocols for easy system setup. Audio input, audio output, and two-way audio are also supported. AI functions work both by camera and by NVR. These include face detection, face recognition, smart motion detection, tripwire, perimeter protection, people counting, safety helmet detection, fire and smoke detection, temperature measurement, and human or vehicle classification. Advanced search and report options such as heatmap, behavior search, face search, and face statistics are available.


Overview of Tiandy TC-R3240 TC-R3232 4HA 2HDD 32ch AI NVR:

  • Up to 32-ch IP camera accesses
  • Incoming/Outgoing bandwidth: 160Mbps(AI on: 120Mbps)/80Mbps
  • S+265, H.265, S+264, H.264 video formats
  • Max. decoding capability: 16MP(30fps)×1 or 1080P(30fps)×10
  • 16-ch synchronous playback
  • Up to 10 TB capacity for each HDD
  • Simultaneous HDMI and VGA outputs
  • HDMI output at up to 4K resolution
  • 1×RJ-45, 10/100/1000 Mbps self-adaptive Ethernet port
  • S+ 265 compression effectively reduces the storage space by up to 75%
  • Support cloud upgrade

The NVR supports two SATA hard drives with up to 10TB capacity per HDD. It supports alarm input and output, USB backup, local HDD storage, and network backup. The unit runs on DC 12V power, uses less than 10W without HDD, supports wide temperature ranges, includes required accessories, and comes with a 1-year brand warranty.
