Tiandy TC-R3120 2MC 1HDD 20ch NVR
Tiandy TC-R3120 2MC 1HDD 20ch NVR
Tiandy TC-R3120 2MC 1HDD 20ch NVR

Tiandy TC-R3120 2MC 1HDD 20ch NVR

Key Features of TC-R3120 2MC:
Up to 20-ch IP camera accesses
Incoming/Outgoing bandwidth: 100Mbps/80Mbps
16-ch synchronous playback
Up to 10 TB capacity for each HDD
Max. decoding capability: 8MP(30fps)×2 or 1080P(30fps)×8

CALL FOR DETAILS: +880 1973-439218
Tiandy TC-R3120 2MC 1HDD 20ch NVR
৳0.00
Add to Cart
Specification Description Reviews
Specification:
Key Features
attr - Key Feature 1 > Up to 20-ch IP camera accesses
attr -Key Feature 2 > Incoming/Outgoing bandwidth: 100Mbps/80Mbps
attr -Key Feature 3 > 16-ch synchronous playback
attr -Key Feature 4 > Up to 10 TB capacity for each HDD
attr -Key Feature 5 > Max. decoding capability: 8MP(30fps)×2 or 1080P(30fps)×8
Call Info >

CALL FOR DETAILS: +880 1973-439218
Tiandy NVR
Video and Audio Access Channel: 20
Incoming Bandwidth: 100Mbps
Outgoing Bandwidth: 80Mbps
Resolution: 8MP/6MP/5MP/4MP/3MP/1080P/UXGA/720P/VGA/4CIF/DCIF/2CIF/CIF/QCIF

Preview Decoding Capability:
8MP(30fps)×2, 6MP(30fps)×2, 5MP(30fps)×3, 4MP(30fps)×4, 3MP(30fps)×5,
1080P(30fps)×8, 720P(30fps)×16, 4CIF(30fps)×20

Playback Decoding Capability:
8MP(30fps)×2, 6MP(30fps)×2, 5MP(30fps)×3, 4MP(30fps)×4, 3MP(30fps)×5,
1080P(30fps)×8, 720P(30fps)×16, 4CIF(30fps)×16

Third-party Camera Access: ONVIF(Profile S/T); RTSP

HDMI Output:
HDMI: 1024×768(60Hz), (720P)1280×720(50Hz/60Hz), 1280×800(60Hz), 1280×1024(60Hz),
1440×900(60Hz), (1080P)1920×1080(50Hz/60Hz), (2K)2560×1440(30Hz), (4K)3840×2160(30Hz)

VGA Output:
VGA: 1024×768(60Hz), (720P )1280×720(50Hz/60Hz), 1280×800(60Hz), 1280×1024(60Hz),
1440×900(60Hz), (1080P)1920×1080(50Hz/60Hz)

Multi-screen Display:
Simultaneous Output:
VGA: 1/2A/2B/3/4/5/6/7/8/9/10/12/13/16/20A/20B/20C/20D/25
HDMI: 1/2A/2B/3/4/5/6/7/8/9/10/12/13/16/20A/20B/20C/20D/25

Audio Output: 1-ch, 3.5mm
Compression Standard Video Compression: S+265; H.265; S+264; H.264
Audio Compression: G.711A; G.711U; AAC; ADPCM_D
Stream Type: Video; Video & Audio
Network Network Protocol:
802.1X; ARP; DDNS; DHCP; DNS; Easy DDNS; FTP; HTTP; HTTPS; ICMP; IGMP;
IPv4; IPv6; Multicast; NFS; NTP; PPPoE; QoS; RTCP; RTP; RTSP; SMB/CIFS;
SMTP; SNMP v1/v2/v3; SRTP; SSH; SSL; TLSv1.2; TCP; UDP; Unicast; UPnP

Mobile Client: EasyLive Plus (Android, iOS)
System Compatibility: ONVIF(Profile S/T/G); RTSP; CGI; SDK; P2P
Web: IE10+; Firefox52+; Edge89+; Safari11+; Chrome57+
Recording Playback Multi-channel Playback: 16
Record Mode: Manual Recording; Alarm Recording; Schedule Recording
Storage Method: Local HDD
Backup: USB storage device, Network

Playback Function: Play/Pause/Stop/Reverse
/Slow/Speed/Backwards 30s/Forwards 30s/Full Screen/
Backup (Video Editing)/Step/Digital Zoom/Instant Replay

Dual Stream Record: Yes
Alarm General Alarm: Motion Detection; Mask Alarm; Alarm Input(IPC)

Exceptions Alarm:
Video Loss; Network Disconnected; No Disk; Illegal Access; Disk group space alert;
Disk Full; Disk R/W Error; Recording Abnormal; Abnormal found in smart of disk;
Abnormal temperature of the disk; Hot-spare Exception; Voltage Alarm(IPC); RTC Failure;
IP Address Conflict; MAC Address Conflict; Disk Overload
Intelligent Analytics AI by Camera:
Tripwire; Double Tripwire; Perimeter; Object Abandon; Object Missing; Running;
Parking; Heatmap; Loitering; Video Abnormal; Audio Abnormal; On Duty Detection;
Crowd Detection; Safety Helmet Detection; Electric Bicycle Detection; People Counting;
Link to Tracking; Smoke and Fire Detection; Environmental Temperature Measurement;
Face Detection; Human Body Temperature Measurement; Smart Alarm; Human/Vehicle Classification

VCA Search:
Early-warning Search; Behavior Search; Safety Helmet Search; Thermographic Retrieval;
Duty Search; Electric Bicycle Retrieval; Face Search(Search by face attributes)

VCA Report: Heatmap; People Counting; Face Statistics
Face Detection Face Attributes Search: Gender; Age; Glasses; Face Mask; Body Temp.
Storage HDD Capacity: Up to 10 TB capacity for each HDD
Disk Group: 1 Disk Group
External Port USB: 2×USB2.0
HDMI: 1×HDMI(supports up to 4K resolution output)
VGA: 1×VGA
Network Interface: 1×RJ-45, 10/100 Mbps self-adaptive Ethernet port
SATA: 1×SATA interface
General UI Language:
Simple Chinese; Traditional Chinese; English; Spanish; Korean; Italian; Turkish;
Russian; Thai; French; Polish; Dutch; Hebrew; Arabic; Vietnamese; German;
Ukrainian; Portuguese; Albanian; Indonesian; Greek

Power Supply: DC12V
Power Consumption: <10W(HDD not included, idling)
NetWeight: 0.8 kg
GrossWeight: 1.45 kg
Boundary Dimensions: 250(L)229(W)45(H)mm
Package Dimensions: 385(L)80(W)280(H)mm
Operating Temperature: -10℃~+55℃ (+14℉~+131℉)
Operating Humidity: 10%~90%RH (non-condensing)
Storage Temperature: -20℃~+60℃ (-4℉~+140℉)

Package Kit:
Network Video Recorder*1; Screw Pack*1; Mouse*1; Power Adapter(DC12V 3A)*1;
European Standard Power Cord*1; Instructions*1; Parts List*1
Warranty 1-Year Brand Warranty
Description:

Tiandy TC-R3120 2MC 1HDD 20ch NVR

Tiandy TC-R3120 2MC 1HDD 20ch NVR is a compact and efficient network video recorder designed for small to mid-size IP surveillance systems. It supports up to 20 IP cameras with 100Mbps incoming and 80Mbps outgoing bandwidth, ensuring stable live view and recording. The NVR works with S+265, H.265, S+264, and H.264 video formats, where S+265 helps reduce storage use by up to 75% while keeping clear video quality. This model supports a wide range of camera resolutions up to 8MP and offers strong decoding ability, allowing 8MP cameras at 30fps or up to eight 1080P channels at the same time. It supports 16-channel synchronous playback and smooth preview and playback for different resolutions. HDMI and VGA outputs work at the same time, with HDMI supporting up to 4K resolution for clear display. Multi-screen display options are available for flexible monitoring layouts.

The TC-R3120 supports third-party IP cameras through ONVIF and RTSP. It includes one 10/100Mbps self-adaptive Ethernet port, dual stream recording, and cloud upgrade support. Audio recording is supported with one audio output. Recording modes include manual, alarm-based, and scheduled recording, while backup can be done through USB or network. This NVR supports AI functions through connected cameras, including motion detection, tripwire, perimeter, people counting, face detection, safety helmet detection, crowd detection, fire and smoke detection, and human or vehicle classification. Advanced search options like behavior search, heatmap reports, and face attribute search are also supported.


Overview of Tiandy TC-R3120 2MC 1HDD 20ch NVR:

  • Up to 20-ch IP camera accesses
  • Incoming/Outgoing bandwidth: 100Mbps/80Mbps
  • S+265, H.265, S+264, H.264 video formats
  • Max. decoding capability: 8MP(30fps)×2 or 1080P(30fps)×8
  • 16-ch synchronous playback
  • Up to 10 TB capacity for each HDD
  • Simultaneous HDMI and VGA outputs
  • HDMI output at up to 4K resolution
  • 1×RJ-45, 10/100 Mbps self-adaptive Ethernet port
  • S+ 265 compression effectively reduces the storage space by up to 75%
  • Support cloud upgrade

It supports one SATA hard drive with up to 10TB capacity. The unit runs on DC 12V power, consumes less than 10W without HDD, and works reliably in different temperatures. The package includes required accessories and comes with a 1-year brand warranty.
