image of Televic CONFIDEA WAP G4 Wireless Access Point with Spec and Price in BDT

Televic CONFIDEA WAP G4 Wireless Access Point

Key Features of CONFIDEA WAP G4:
Televic Wireless Access Point
WiFi5 Supported
Mix-Minus mode
Omni-directional range of 40M
Compatibility with Televic T-CAM camera tracking solution

CALL FOR DETAILS: +880 1969 633-053
Televic CONFIDEA WAP G4 Wireless Access Point
Based on 0 reviews. - Write a review
৳0.00
Add to Cart
Specification Description Reviews
Specification:
Key Features
attr - Key Feature 1 > Televic Wireless Access Point
attr -Key Feature 2 > WiFi5 Supported
attr -Key Feature 3 > Mix-Minus mode
attr -Key Feature 4 > Omni-directional range of 40M
attr -Key Feature 5 > Compatibility with Televic T-CAM camera tracking solution
Call Info >

CALL FOR DETAILS: +880 1969 633-053
Televic
Mechanical Material: ABS
Color: White
Size: (W x H x D) 191 × 45 × 191 mm, 7.52 x 1.77 x 7.52 in
Size packed: (W x H x D) 233 × 46 × 233 mm, 9.17 x 1.81 x 7.52 in
Weight: 680 g, 1.50 lb
Weight packed: 825 g, 1.82 lb
Mounting type: wall, ceiling, electrical box, microphone stand
Electrical Supply type: PoE+, 802.3at, Type 2 PD
Typical power consumption: 15 W
Max power consumption: 24 W
System Encryption type: WPA2 Enterprise
Max number of units: 128
Max number of open
microphones: 8
Latency (microphone to WAP - WAP to loudspeaker): 16 ms
Audio: 48 kHz / 24 bit
Frequency response: 20 - 20 kHz
THD (22 - 22000 Hz): < 0.02 %
Dynamic range: > 90 dB
Signal-to-noise: ratio > 95 dBA
RF WiFi standard: WiFi5, IEEE802.11ac
RF frequency bands: 2.4 GHz / 5 GHz
ERP (Equivalent Isotropically Radiated power): < 24 dBm
Range: 40 m
Antenna No of antennas: 5
LAN Interface: Ethernet
Link speed: 100 Mbps
Network addressing: DHCP, NTP, or Manual
Cable type > Cat5e (shielded)
Connector: RJ45
Connector LED Green: Link
Orange: Link activity
Cable Length: 100 m (max)
Security Authentication: 802.1X (MD5, TLS, PEAPMSCHAPv2) for LAN port only
Plixus Interface: Ethernet
Link speed: 100 Mbps
Power: 48 VDC
Continuous output current: 2A
Cable type: > Cat5e (shielded)
Connector: RJ45
Connector LED Green: Status
Orange: Link speed
Cable Length: 80 m (max)
Recording Format: MP3
Quality: 64, 128, 196, 256 kbps
Maximum size: 500 GB
USB Interface: USB2.0
Format: NTFS
Maximum size: 500 GB
Internal Storage Size: 4 GB
Audio Input Nominal input level: 0 dBV
Max input level: +10 dBV
Frequency response: 20 - 20 kHz
THD @ nominal level (22 - 22 kHz): < 0,02 %
Dynamic Range: > 90 dB
SNR: > 95 dBA
Input impedance: > 10 kΩ
Configuration Balanced
Connector type: 3-pin, Phoenix mini combicon
Audio output Nominal output level: 0 dBV
Max output level: + 10 dBV
Frequency response:20 - 20000 Hz
THD @ nominal level (22 - 22000Hz): < 0,02 %
Dynamic Range: > 90 dB
Load impedance: > 600 Ω
Configuration Balanced
Connector type: 3-pin, Phoenix mini combicon
Environment Operating temperature: 0 – 45°C
Storage and transport temperature: -20 – 60°C
Humidity: <95%, >5%
Warranty 3-Year Brand Warranty
Description:

Televic CONFIDEA WAP G4 Wireless Access Point

Televic CONFIDEA WAP G4 Wireless Access Point is the core of a reliable wireless conference system. This access point offers powerful tools to optimize channel use within the RF spectrum and secure links with wireless conference units. Its built-in web-based software provides step-by-step wizards for easy setup and configuration. With an additional license, you unlock meeting management tools including moderation, voting, participant identification, and reporting. The access point supports both analog and digital (Dante) interfaces, making it compatible with third-party audio systems like Zoom and Teams. Power can be supplied via a PoE+ switch or power injector. The system offers easy recording options on internal or external storage.

Key features include automatic channel management, interference avoidance, and battery status visualization. It also supports device discovery via physical button or web software, audio routing for external processing, and compatibility with Televic T-CAM camera tracking. The Confidea WAP G4 includes Confero software for easy system configuration and monitoring, and Confero 360 management software for enhanced meeting preparation and reporting. User roles and meeting templates can be customized, and identification badges linked to participants for easy login and identification.

Buy Televic CONFIDEA WAP G4 Wireless Access Point in Bangladesh

You can buy your desired Televic CONFIDEA WAP G4 Wireless Access Point at Global Brand PLC. We are the authorized distributor of Televic in Bangladesh. You buy online and enjoy free home delivery. You can also visit any of our branches near you.
