Tiandy TC-H363N Spec:I5W/WIFI/Eu/4mm/V4.0 6MP Fixed Color Maker Wi-Fi PT Camera
Tiandy TC-H363N Spec:I5W/WIFI/Eu/4mm/V4.0 6MP Fixed Color Maker Wi-Fi PT Camera
Tiandy TC-H363N Spec:I5W/WIFI/Eu/4mm/V4.0 6MP Fixed Color Maker Wi-Fi PT Camera
Tiandy TC-H363N Spec:I5W/WIFI/Eu/4mm/V4.0 6MP Fixed Color Maker Wi-Fi PT Camera

Tiandy TC-H363N Spec:I5W/WIFI/Eu/4mm/V4.0 6MP Fixed Color Maker Wi-Fi PT Camera

Key Features of TC-H363N Spec:I5W/WIFI/Eu/4mm/V4.0:
Up to Panorama:3MP,2304×1296@15fps Detail:3MP,2304×1296@15fps
Plastic housing
IR range up to 50m
1×Built-in Mic, 1×Built-in Loudspeaker
Support microSD/microSDHC/microSDXC card, up to 512GB

CALL FOR DETAILS: +880 1973-439218
Tiandy TC-H363N Spec:I5W/WIFI/Eu/4mm/V4.0 6MP Fixed Color Maker Wi-Fi PT Camera
৳0.00
Add to Cart
Specification Description Reviews
Specification:
Key Features
attr - Key Feature 1 > Up to Panorama:3MP,2304×1296@15fps Detail:3MP,2304×1296@15fps
attr -Key Feature 2 > Plastic housing
attr -Key Feature 3 > IR range up to 50m
attr -Key Feature 4 > 1×Built-in Mic, 1×Built-in Loudspeaker
attr -Key Feature 5 > Support microSD/microSDHC/microSDXC card, up to 512GB
Call Info >

CALL FOR DETAILS: +880 1973-439218
Tiandy CCTV Camera
Camera Image Sensor: 1/3"CMOS
Min. Illumination: Color:0.02Lux@(F1.6,AGC ON),B/W:0Lux with IR
Shutter Time: 1s~1/100000s
Day&Night: IR-cut filter with auto switch (ICR)
Smart IR: Yes
WDR: DWDR
S/N: >40dB

Angle Adjustment:
Panorama:-60~60°(P)
Details:0~345°(P); Panorama:5~15°
Details:-15~90°
Lens Lens Type: Fixed focal lens
Focal Length: 4mm
Lens Mount: M12
Aperture Range: F1.6
Aperture Type: Fixed

Field of View:
Panorama:81.3°(H);
Detail:81.3°(H); Panorama:44.4°(V);
Detail:44.4°(V); Panorama:94.4°(D);
Detail:94.4°(D)

DORI Distance:
Detect:59.26m
Observe:23.52m
Recognize:11.85m
Identify:5.93m
Pan & Tilt Pan Speed: 30°/s
Tilt Speed: 25°/s
Preset: 255
Illuminator IR LEDs:
Panorama:4
Detail:4

IR Distance: Up to 50m
Wavelength: 850nm

White LEDs:
Panorama:4
Detail:4

Whitelight Distance: 15m
Red and Blue Alarm Flash: Yes
Compression Standard Video Compression: S+265/H.265/H.264B/H.264M/H.264H
Video Bit Rate: 32k~4Mbps
Audio Compression: G.711A/G.711U
Audio Sampling Rate: 8kHz/16kHz
Image Max. Resolution:
Panorama:3MP,2304×1296@15fps
Detail:3MP,2304×1296@15fps

Main Stream:
Panorama:
PAL:15fps(2304×1296, 1920×1080, 1280×720, 704x576, 640x480)
NTSC:15fps(2304×1296, 1920×1080, 1280×720, 704x576, 640x480)
Detail:
PAL:15fps(2304×1296, 1920×1080, 1280×720, 704x576, 640x480)
NTSC:15fps(2304×1296, 1920×1080, 1280×720, 704x576, 640x480)

Sub Stream:
Panorama:
PAL:15fps(704×576, 704×288, 640×360, 352×288)
NTSC:15fps(704×480, 704×240, 640×360, 352×240)
Detail:
PAL:15fps(704×576, 704×288, 640×360, 352×288)
NTSC:15fps(704×480, 704×240, 640×360, 352×240)

BLC: Yes
HLC: Yes
AGC: Yes
3D DNR: Yes

White Balance:
Auto/Semi-Auto/Manual/Sunshine/Nature Light/Warmlight Lamp/
Daylight Lamp/Filament Lamp/Lock White Balance

OSD:
Overlay of additional characters in 1 regions, 1 line,
with a maximum of 48 characters or 16 Chinese characters per region; 16*16/32*32/48*48; Lattice

Privacy Mask: 4 black static areas
Defog: Yes
Feature Exceptions Alarm: Voltage Alarm; Disk Full; Disk R/W Error; IP Address Conflict; Network Disconnection
Linkage Method: Trigger Sound; Trigger Recording; Trigger Capture; Notify Surveillance Center
Video Analytics: Smart Alarm
Auto-Tracking: Yes
Network ANR: Yes
Protocols: HTTP; TCP; UDP; ICMP; DHCP; DNS; NTP; TLS v1.2; IPv4; SSH; Unicast; FTP
System Compatibility: ONVIF(Profile S/T) ; SDK; CGI
Remote Connection: ≤2
Client: Easy7 VMS
Mobile Client: EasyLive Plus
Web: IE10+; Firefox52+; Edge89+; Safari11+; Chrome57+
Wi-Fi Transmission Distance: Up tp 50m( based on actual environment)
Wireless Standard: IEEE802.11b/ 802.11g/802.11n
Frequency Range: 2.4 GHz ~ 2.4835 GHz
Channel Bandwidth: 20/40MHz
Wi-Fi Security: WPA-PSK/WPA2-PSK
Interface Communication Interface: 1×RJ-45 (10/100 Base-T)
Built-in Mic: 1×Built-in Mic
Built-in Speaker: 1×Built-in Loudspeaker
Reset Button: Yes
On-board Storage: Support microSD/microSDHC/microSDXC card,up to 512GB
General Web Client Language:
3 languages
Simple Chinese/English/Vietnamese

Operating Temperature: -30℃~60℃(-22℉~140℉)
Operating Humidity: ≤95%RH
Storage Temperature: -30℃~60℃(-22℉~140℉)
Storage Humidity: 10%~95%RH(non-condensing)
Power Supply: DC12V±25%,Max. 13W
Protection: Surge4000V; ESD6000V; IP66
Boundary Dimensions: 133(L)102(W)209(H)mm
Package Dimensions: 160(L)160(W)215(H)mm
GrossWeight: 0.83kg
Warranty 1-Year Brand Warranty
Description:

Tiandy TC-H363N Spec:I5W/WIFI/Eu/4mm/V4.0 6MP Fixed Color Maker Wi-Fi PT Camera

Tiandy TC-H363N Spec:I5W/WIFI/Eu/4mm/V4.0 6MP Fixed Color Maker Wi-Fi PT Camera is a high-performance outdoor security camera designed for wide area monitoring with clear day and night video. It uses a 1/3" CMOS sensor and delivers dual 3MP streams for panorama and detail views at 2304×1296 resolution with 15fps. The fixed 4mm lens with F1.6 aperture provides a wide field of view up to 94.4° diagonal and supports DWDR, Smart IR, 3D DNR, BLC, HLC, and AGC for balanced images in different light conditions.

This Wi-Fi PT camera supports pan and tilt movement with fast pan speed up to 30°/s and tilt speed up to 25°/s, along with 255 presets and auto-tracking for smart monitoring. Color video works in very low light at 0.02 Lux, and night vision is supported by IR LEDs with up to 50m range and white LEDs up to 15m. Red and blue alarm flash lights add visual warning when alarms are triggered. The camera supports S+265, H.265, and H.264 compression to reduce storage use, with video bit rate from 32k to 4Mbps. Built-in microphone and speaker allow two-way audio using G.711 audio format. Local storage is supported through microSD cards up to 512GB.

It supports smart alarms, ANR, and multiple network protocols including ONVIF Profile S/T. Remote access is available through Easy7 VMS, EasyLive Plus mobile app, and major web browsers. Wi-Fi works on 2.4GHz with up to 50m range depending on the environment. The camera has a plastic housing with IP66 protection, works in extreme temperatures from -30℃ to 60℃, and runs on DC12V power with a maximum of 13W. It comes with a 1-year brand warranty.

Buy Tiandy TC-H363N Spec:I5W/WIFI/Eu/4mm/V4.0 6MP Fixed Color Maker Wi-Fi PT Camera in Bangladesh

You can buy your desired Tiandy TC-H363N Spec:I5W/WIFI/Eu/4mm/V4.0 6MP Fixed Color Maker Wi-Fi PT Camera at Global Brand PLC. We are the authorised distributor of Tiandy in Bangladesh. You buy online and enjoy free home delivery. You can also visit any of our branches near you.
