Cudy GS5048S4 48-GbE 4-SFP+ L3 Managed Gigabit Switch
Cudy GS5048S4 48-GbE 4-SFP+ L3 Managed Gigabit Switch
Cudy GS5048S4 48-GbE 4-SFP+ L3 Managed Gigabit Switch
Cudy GS5048S4 48-GbE 4-SFP+ L3 Managed Gigabit Switch

Cudy GS5048S4 48-GbE 4-SFP+ L3 Managed Gigabit Switch

Key Features of GS5048S4:
48-GbE, 4-SFP+, Layer 3 switch with a silent, Fanless cooling system
Support multiple VLAN division, MAC VLAN, Protocol VLAN, Private VLAN
Fanless and Silent Cooling
L3 Managing Features
Surge Protection: General 4KV, Differential 2KV, ESD 8KV air, 6KV contact
Cudy GS5048S4 48-GbE 4-SFP+ L3 Managed Gigabit Switch
Based on 0 reviews. - Write a review
৳61,000.00
Add to Cart
Buy Now
Specification Description Reviews
Specification:
Key Features
attr - Key Feature 1 > 48-GbE, 4-SFP+, Layer 3 switch with a silent, Fanless cooling system
attr -Key Feature 2 > Support multiple VLAN division, MAC VLAN, Protocol VLAN, Private VLAN
attr -Key Feature 3 > Fanless and Silent Cooling
attr -Key Feature 4 > L3 Managing Features
attr -Key Feature 5 > Surge Protection: General 4KV, Differential 2KV, ESD 8KV air, 6KV contact
Cudy Switch
Model GS5048S4 1.0
Technical Parameters AC INPUT:
- AC INPUT (100-240V)
- 48 * 10/100/1000 Mbps RJ45 Port

Ethernet Port:
- 4 * 10G SFP+ Port
- 1 * RJ45 Console Port
- 1 * USB Port

Bandwidth: 176 Gbps
Packet Forwarding Rate: 131 Mpps
DDR SDRAM: 512 MB
Flash Memory: 32 MB
Packet Buffer Memory: 16 Mbit
MAC Address: 32 K
Jumbo Frame: 12 Kbytes
VLANs: 4096
Standard Network Protocols:
IEEE 802.3: Ethernet MAC Protocol
IEEE 802.3i: 10BASE-T Ethernet
IEEE 802.3u: 100BASE-TX Fast Ethernet
IEEE 802.3ab: 1000BASE-T Gigabit Ethernet
IEEE 802.3z: 1000BASE-X Gigabit Ethernet (optical fiber)
IEEE 802.3ae: 10G Ethernet (optical fiber)
IEEE 802.3az: Energy Efficient Ethernet
IEEE 802.3ad: Standard method for performing link aggregation
IEEE 802.3x: Flow control
IEEE 802.1ab: LLDP/LLDP-MED (Link Layer Discovery Protocol)
IEEE 802.1p: LAN Layer QoS/CoS Protocol Traffic Prioritization (Multicast filtering function

IEEE 802.1q: VLAN Bridge Operation
IEEE 802.1x: Client/Server Access Control and Authentication Protocol
IEEE 802.1d: STP
IEEE 802.1s: MSTP
IEEE 802.1w: RSTP

Industry Standard:
- EMI: FCC Part 15 CISPR (EN55032) class A
- EMS: EN61000-4-2 (ESD), EN61000-4-4 (EFT)
- EN61000-4-5 (Surge)

Network Media:
10BASE-T: Cat3、4、5 or above UTP (≤100 M)
100BASE-TX: Cat5 or above UTP (≤100 M)
1000BASE-TX: Cat5 or above UTP (≤100 M)
Multi-mode Fiber: 50/125、62.5/125、100/140 um
Single-mode Fiber: 8/125、8.7/125、9/125、10/125 um
Environmental Standards Working Environment:
Operating temperature: -10~50°C
Storage temperature: -40~70°C
Operating Humidity: 10%~90%, No condensation
Storage Humidity: 5%~90%, No condensation
Function Indication Indicator Light:
PWR (Power indicator)
SYS (System lights)
Link/ACT (Link light/data light)
Software Function Basic function:
Support hardware watchdog, factory reset, system, and port LED
Support global information, statistical information, and log information
Support User management, alarm management, and configuration management
Support Port rate, duplex, flow control, maximum frame length configuration.
Support Port mirroring, port speed limit, port energy saving

Layer 3 Interface:
Support Layer 3 interface
Support IPv4, IPv6 address configuration
Support ARP configuration
Support ND configuration

Layer 3 Routing:
Support IPv4 static routing
Support IPv6 static routing
Support RIP V1/V2
Support OSPF

DHCP:
Support DHCP server
Support DHCP relay
Support DHCP Snooping
Physical Specifications Product Information:
Product Dimensions: 440*280*44 mm
Package Dimensions: 500*365*85 mm
Product N.W: 3.87 KG
Product G.W: 4.70 KG

Packing Information:
Carton Dimensions: 520*445*385 mm
Packing Quantity: 5 pcs

Voltage: Input Voltage: AC 100-240 V/50-60 Hz

VLAN:
Support 4K VLAN
Support 802.1Q VLAN, based on port VLAN
Support Access Trunk, Hybrid VLAN mode
Support GVRP (VLAN registration protocol)
Support MAC VLAN, IP VLAN
Support Voice VLAN

MAC Address:
Support MAC address automatic learning and aging
Support Static, dynamic, filtered address table

Security Features:
Password protection
Support Restrict user access based on port number, IP address, and MAC address
Support HTTPS、SSH V1/V2
Support IP-MAC-PORT-VLAN binding
Support ARP detection, IP source protection, and DoS protection
Support DHCP Snooping、DHCP Attack protection
Support 802.1X Certification
SupportAAA (Authentication, Authorization, Account- ing), Support RADIUS protocal,TACACS+ Support Port security, port isolation

Access control:
Support L2(Layer 2)～L4(Layer 4) Packet filtering function
Support Port mirroring, flow rate limiting, QoS remarking

QOS:
Support 8-port queues
Support Port priority, 802.1P priority, DSCP priority
Support SP, WRR Priority scheduling algorithm

Spanning Tree:
Support STP(IEEE 802.1d), RSTP(IEEE 802.1w) and MSTP(IEEE 802.1s) protocal
Support Multi-instance, Support Aggregate interface
Support BPDU protection

Multicast:
Support IGMP v1/v2/v3 Snooping
Support MLD v1/v2 Snooping
Support Layer 2 multicast fast leave mechanism, querier
Support Layer 2 IPv4 static multicast
Support Layer 2 IPv6 static multicast
Support IGMP v1/v2/v3 Layer 3 multicast

Storm Suppression:
Support multicast suppression
Support broadcast storm suppression
Support unknown unicast suppression

Ring Protection:
Support Ring protection

Link Aggregation:
Support Static Aggregation
Support LACP Dynamic Aggregation
Support based on IP, MAC, mixed load-balancing modes
Maximum support 32 aggregation groups (8 ports per aggregation group)

IPv6:
Support IPv6 Ping, IPv6 Traceroute, IPv6 Telnet
Support IPv6 SSH
Support IPv6 HTTP, IPv6 HTTPS

Management and Maintenance:
Support WEB Management (HTTP, HTTPS)
Support CLI (Telnet, SSH V1/V2, Local serial port)
Support SNMP V1/V2/V3 Support RMON V2
Support LLDP Device discovery
Support SNTP Time synchronization
Support CPU Monitoring, Memory Monitoring
Support System log, classification warning
Support Ping, Traceroute detection, cable detection
Warranty 01-Year Brand Warranty
Description:

Cudy GS5048S4 48-GbE 4-SFP+ L3 Managed Gigabit Switch

Cudy GS5048S4 48-GbE 4-SFP+ Layer 3 Managed Gigabit Switch is a sure thing for large networks that need quick data, longer control, and powerful security. It offers industry-standard support like IEEE 802.1d, 802.1w, 802.1s, 802.1p, 802.3, 802.3u, 802.3x, 802.3z, 802.3ab, and 802.3ae to provide wide compatibility and smooth operation on all platforms. The switch has 48 Gigabit Ethernet ports and 4 10G SFP+ uplink slots, handling large traffic flows and providing distant connectivity through fiber. L3 management functions include DHCP Server support, QoS for priority control of traffic, ACL for controlling access to traffic, SNMP v1/v2/v3, and IGMP Snooping v1/v2 for multicast management.

The switch delivers high Layer 2 and Layer 3 performance. STP, RSTP, MSTP, and ERPS are supported to offer better loop protection and network stability. Loop detection, self-healing, and remote loopback monitoring of 802.3ah OAM allow customers to easily identify and fix issues. Support for IPv4 and IPv6, and routing protocols RIP and OSPF, prepares it for the demands of modern networks. Advanced VLAN features include multiple VLAN partitioning, MAC VLAN, Protocol VLAN, and Private VLAN for traffic security and isolation. Network protection includes IP + MAC + VLAN + Port binding, DHCP Snooping, and IP source guard with DAI (Dynamic ARP Inspection).

With security in its design, the switch boasts strong surge protection: 4KV general, 2KV differential, and ESD protection that includes 8KV air discharge and 6KV contact discharge. These shield your network from power surges and static damage. Cudy GS5048S4 is a suitable choice for business networks, data centers, or campus setups demanding strong performance, full control, and safe operation.

Buy Cudy GS5048S4 48-GbE 4-SFP+ L3 Managed Gigabit Switch in Bangladesh

You can buy your desired Cudy GS5048S4 48-GbE 4-SFP+ L3 Managed Gigabit Switch at Global Brand PLC. We are the authorized distributor of CUDY in Bangladesh. You buy online and enjoy free home delivery. You can also visit any of our branches near you.
