ASUS ROG STRIX H470-I Mini ITX GAMING Motherboard
Out Of Stock
ASUS ROG STRIX H470-I Mini ITX GAMING Motherboard

ASUS ROG STRIX H470-I Mini ITX GAMING Motherboard

Key Features:
Key Features
attr - Key Feature 1 > Chipset: Intel® H470 for 10th Gen Intel® Core™, Pentium® Gold and Celeron® Processors
attr -Key Feature 2 > Socket: LGA1200
attr -Key Feature 3 > m.2 slots: 2x M.2 slots with PCIe 3.0 support
attr -Key Feature 4 > USB: 4x Front ports 7x Rear ports
attr -Key Feature 5 > Memory: 2 x DIMM, Max. 64GB, DDR4
Motherboard
CPU Intel® Socket 1200 for 10th Gen Intel® Core™, Pentium® Gold and Celeron® Processors Supports Intel® Turbo Boost Technology 2.0 and Intel® Turbo Boost Max Technology 3.0
Chipset Intel® H470
Graphics 1 x DisplayPort 1.4 ** **Support DisplayPort 1.4 with max. resolution of 4096 x 2304 @60Hz. Please refer to www.intel.com for any update. 1 x HDMI 1.4b *Graphics specifications may vary between CPU types.
Expansion Slots Intel® 10th Gen Processors
1 x PCIe 3.0 x16
Storage
1 x M.2_1 socket 3, with M Key, Type 2242/2260/2280 (PCIE 3.0 x4 and SATA modes) storage devices support*2
PCI 3.0
Internal I/O Ports 1 x USB 3.2 Gen 1(up to 5Gbps) connector(s) support(s) additional 2 USB 3.2 Gen 1 port(s)
1 x Aura RGB Strip Headers
2 x M.2 Socket 3
1 x CPU Fan connector(s)
1 x Chassis Fan connector(s)
1 x AIO_PUMP connector
1 x AAFP connector
2 x Addressable Gen 2 header(s)
1 x USB 2.0 connector(s) support(s) additional 2 USB 2.0 port(s)
1 x M.2 with E key for Wi-Fi module
1 x COM port(s) connector(s)
4 x SATA 6Gb/s connector(s)
1 x S/PDIF out header(s)
1 x 24-pin EATX Power connector(s)
1 x 8-pin ATX 12V Power connector(s)
1 x Clear CMOS jumper(s)
1 x System panel connector
Memory Slots 2
Memory Type DDR4
USB 1 x USB 2.0 port(s)(1 x USB Type-C®)
Front USB Port ( Total 4 )
Rear USB Port ( Total 7 )
4 x USB 3.2 Gen 1 port(s)(4 x Type-A)
2 x USB 3.2 Gen 2 port(s)
2 x USB 3.2 Gen 1 port(s)
2 x USB 2.0 port(s)
Audio ROG SupremeFX7.1 Surround Sound High Definition Audio CODEC
– Rear audio USB Type-C® port
– Premium Japanese audio capacitors
– Dual OP Amplifiers
– Impedance sense for front and rear headphone outputs
– Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking
– High quality120dBSNR stereo playback outputand113dBSNR recording input
– Supports up to 32-Bit/192kHz playback
Maximum Memory 64GB
BIOS 128 Mb Flash ROM, UEFI AMI BIOS
Form Factor Mini ITX Form Factor 6.7 inch x 6.7 inch ( 17 cm x 17 cm )
Warranty 3 Years Replacement
৳0
Specification:
Key Features
attr - Key Feature 1 > Chipset: Intel® H470 for 10th Gen Intel® Core™, Pentium® Gold and Celeron® Processors
attr -Key Feature 2 > Socket: LGA1200
attr -Key Feature 3 > m.2 slots: 2x M.2 slots with PCIe 3.0 support
attr -Key Feature 4 > USB: 4x Front ports 7x Rear ports
attr -Key Feature 5 > Memory: 2 x DIMM, Max. 64GB, DDR4
Motherboard
CPU Intel® Socket 1200 for 10th Gen Intel® Core™, Pentium® Gold and Celeron® Processors Supports Intel® Turbo Boost Technology 2.0 and Intel® Turbo Boost Max Technology 3.0
Chipset Intel® H470
Graphics 1 x DisplayPort 1.4 ** **Support DisplayPort 1.4 with max. resolution of 4096 x 2304 @60Hz. Please refer to www.intel.com for any update. 1 x HDMI 1.4b *Graphics specifications may vary between CPU types.
Expansion Slots Intel® 10th Gen Processors
1 x PCIe 3.0 x16
Storage
1 x M.2_1 socket 3, with M Key, Type 2242/2260/2280 (PCIE 3.0 x4 and SATA modes) storage devices support*2
PCI 3.0
Internal I/O Ports 1 x USB 3.2 Gen 1(up to 5Gbps) connector(s) support(s) additional 2 USB 3.2 Gen 1 port(s)
1 x Aura RGB Strip Headers
2 x M.2 Socket 3
1 x CPU Fan connector(s)
1 x Chassis Fan connector(s)
1 x AIO_PUMP connector
1 x AAFP connector
2 x Addressable Gen 2 header(s)
1 x USB 2.0 connector(s) support(s) additional 2 USB 2.0 port(s)
1 x M.2 with E key for Wi-Fi module
1 x COM port(s) connector(s)
4 x SATA 6Gb/s connector(s)
1 x S/PDIF out header(s)
1 x 24-pin EATX Power connector(s)
1 x 8-pin ATX 12V Power connector(s)
1 x Clear CMOS jumper(s)
1 x System panel connector
Memory Slots 2
Memory Type DDR4
USB 1 x USB 2.0 port(s)(1 x USB Type-C®)
Front USB Port ( Total 4 )
Rear USB Port ( Total 7 )
4 x USB 3.2 Gen 1 port(s)(4 x Type-A)
2 x USB 3.2 Gen 2 port(s)
2 x USB 3.2 Gen 1 port(s)
2 x USB 2.0 port(s)
Audio ROG SupremeFX7.1 Surround Sound High Definition Audio CODEC
– Rear audio USB Type-C® port
– Premium Japanese audio capacitors
– Dual OP Amplifiers
– Impedance sense for front and rear headphone outputs
– Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking
– High quality120dBSNR stereo playback outputand113dBSNR recording input
– Supports up to 32-Bit/192kHz playback
Maximum Memory 64GB
BIOS 128 Mb Flash ROM, UEFI AMI BIOS
Form Factor Mini ITX Form Factor 6.7 inch x 6.7 inch ( 17 cm x 17 cm )
Warranty 3 Years Replacement
